ECUMASTER Map-sensor MAP-400
ECU master
400kPa
Reviews
Help others choose right. Be the first to write a review!
Write a reviewECUMASTER MAP Sensor MAP-400
The Ecumaster 400kPa MAP (Manifold Absolute Pressure) sensor is a pressure sensor that delivers precise and stable performance at an affordable price. It operates by converting absolute pressure into an electrical voltage signal.
This versatile sensor can accurately measure pressure, from vacuum conditions to "boost pressure" up to 300 kPa, making it an ideal choice for various vehicle applications.
Features:
- Supply voltage: 5.0 V
- Supply current: < 10 mA
- Pressure range: 20 to 400 kPa
- Full-scale output: 4.6 V
- Sensitivity: 12.1 mV/kPa
- Operating temperature: -25 °C to 125 °C
- Accuracy: +/- 1.5%
- Enclosure: PA6-GF15 plastic mold
- IP67
- Maximum pressure: 1600 kPa (232 psi)
- Maximum output voltage: 5.5 V
- Maximum load current: +/- 0.5 mA
----------------
